INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/159P
shall be completed by 4 May 2009.
4 February 2009
SUPERSEDING
MIL-PRF-19500/159N
1 APRIL 2008
PERFORMANCE SPECIFICATION SHEET
* SEMICONDUCTOR DEVICE, DIODE, SILICON, TEMPERATURE COMPENSATED,
VOLTAGE-REFERENCE, TYPES 1N821-1, 1N823-1, 1N825-1, 1N827-1, AND 1N829-1,
1N821UR-1, 1N823UR-1, 1N825UR-1, 1N827UR-1, AND 1N829UR-1, JAN, JANTX, JANTXV, JANS,
JANHC AND JANKC; RADIATION HARDENED (TOTAL DOSE ONLY) TYPES JANTXVM, D, L, R, F, G, H;
JANSM, D, L, R, F, G, H; JANHCM, D, L, R, F, G, H; AND JANKCM, D, L, R, F, G, H
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
* 1.1 Scope. This specification covers the performance requirements for 6.2 volts 5 percent, silicon, temperature
compensated, voltage-reference diodes. Four levels of product assurance are provided for each encapsulated device
type as specified in MIL-PRF-19500, and two levels of product assurance are provided for each unencapsulated
device type. Seven levels of radiation hardened (total dose only) product assurance are provided for each
encapsulated device type as specified in MIL-PRF-19500, and two levels of product assurance for each
unencapsulated device type.
1.2 Physical dimensions. See figure 1 (similar to DO-7 and DO-35), figure 2 (similar to DO-213AA), figure 3
(JANHCA and JANKCA), figure 4 (JANHCB and JANKCB) and figure 5 (JANHCC and JANKCC).
1.3 Maximum ratings. Unless otherwise specified TA = +25C.
PT
IZM
TSTG and TJ
Power derating
above TA = +25C
(1)
(1)
C
mW/C
mW
mA dc
500
-55 to +175
70
3.33
(1) To guarantee voltage temperature stability, it is necessary to maintain the proper IZ = 7.5 mA dc.
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil . Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
