INCH-POUND
MIL-PRF-19500/619B
28 April 2000
SUPERSEDING
MIL-PRF-19500/619A
11 November 1997
PERFORMANCE SPECIFICATION
SEMICONDUCTOR DEVICE, DIODE, SCHOTTKY POWER RECTIFIERS,
TYPES 1N6849 1N6856, 1N6849U1 1N6856U1
1N6849U2 1N6856U2 and 1N6849U3 1N6856U3
JAN, JANTX AND JANTXV
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for schottky power surface mount rectifiers.
Three levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (surface mount).
1.3 Maximum ratings.
Column 1
Column 2
Column 3
Column 4
Column 5
Column 6
Peak
Maximum 4/
IFSM 3/
TSTG
TOP
IO 2/
Types 1/
thermal resistance
inverse
voltage
TC = +100°C
°C/W 5/
°C/W 6/
°C
°C
V dc
A dc
A (pk)
-65 to +175
-65 to +150
0.45
0.20
1,000
30
110
1N6849/U1/U2/U3
0.45
-65 to +175
0.20
1,000
45
150
1N6850/U1/U2/U3
0.45
-65 to +175
0.20
120
900
1N6851/U1/U2/U3
100
-65 to +150
0.80
0.35
900
30
60
1N6852/U1/U2/U3
-65 to +175
0.80
0.35
900
45
75
1N6853/U1/U2/U3
-65 to +175
0.80
0.35
900
60
1N6854/U1/U2/U3
100
1N6855/U1/U2/U3
45
10
300
0.85
1.40
-65 to +175
1N6856/U1/U2/U3
100
10
300
0.85
1.40
-65 to +175
1/
See 1.5 for type designation/lead configuration.
Derate the IO linearly to zero at 100°C to the maximum operating temperature.
2/
IFSM, tp = 8.3 ms, TC = +25°C, VR = PIV.
3/
4/
Maximum thermal resistance junction to cathode surface.
5/
Thermal resistance value for package outline basic version, U1 version and U2 version.
6/
Thermal resistance value for package outline U3 version.
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be of use in improving this document
should be addressed to: Commander, Defense Supply Center Columbus, ATTN: DSCC-VAC, 3990 East Broad Street, Columbus, OH
43216-5000, by using the Standardization Document Improvement Proposal (DD Form 1426) appearing at the end of this document or
by letter.
AMSC N/A
FSC 5961
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
