MIL-PRF-19500-619 Semiconductor Device, Diode, Schottky Power Rectifiers, Types 1N6849 - 1N6856, 1N6849U1 - 1N6856U1, 1N6849U2 - 1N6856U2, And 1N6849U3 - 1N6856U3 Jan, Jantx And JantxvThis specification covers the performance requirements for schottky power surface mount rectifiers. Three levels of product assurance are provided for each device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/619B
Basic Version
U1 Version
U3 Version
U2 Version
Package outline
A
B
C
D
G
H
J
R
T
U
1N6855, 1N6856
0.225
0.225
---
---
---
0.075 max
---
---
---
---
1N6852 - 1N6854
0.315
0.315
---
---
---
0.075 max
---
---
---
---
1N6849 - 1N6851
0.410
0.410
---
---
---
0.075 max
---
---
---
---
1N6855U1, 1N6856U1
0.225
0.225
0.375
0.125
0.060
0.075 max
---
0.020
0.020
---
1N6852U1 - 1N6854U1
0.315
0.315
0.465
0.170
0.060
0.075 max
---
0.020
0.020
---
1N6849U1 - 1N6851U1
0.410
0.410
0.550
0.200
0.060
0.075 max
---
0.020
0.020
---
1N6855U2, 1N6856U2
0.225
0.225
0.375
0.150
0.060
0.090 max
---
0.020
0.015
0.015
1N6852U2 - 1N6854U2
0.315
0.315
0.465
0.150
0.060
0.090 max
---
0.020
0.015
0.015
1N6849U2 - 1N6851U2
0.410
0.410
0.560
0.150
0.060
0.090 max
---
0.020
0.015
0.015
1N6855U3, 1N6856U3
0.225
0.225
0.405
0.150
0.190
0.138 max
0.037
---
0.012
---
1N6852U3 - 1N6854U3
0.315
0.315
0.495
0.150
0.190
0.138 max
0.037
---
0.012
---
1N6849U3 - 1N6851U3
0.410
0.410
0.590
0.150
0.190
0.138 max
0.037
---
0.012
---
±0.010
±0.010
±0.020
±0.010
±0.010
±0.005
±0.005
±0.002
±0.005
Tolerances
---
NOTE: All dimensions are in inches.
FIGURE 1. Physical dimensions.
