MIL-PRF-19500/116S
TABLE II. Group E inspection (all quality levels) for qualification and requalification only.
MIL-STD-750
Qualification
Inspection
inspection
Method
Conditions
Subgroup 1
n = 45, c = 0
100 cycles 0°C to +100°C
Thermal shock (glass
1056
strain)
500 cycles, -65°C to +175°C
Temperature cycling
1051
Hermetic seal
1071
Fine and gross leak required for UB suffix devices.
Gross leak only for non-UB parts.
Electrical measurement
See table I, subgroup 2
Subgroup 2
n = 45, c = 0
10,000 cycles; If = 300 mA dc, Ton = Toff = 1 minute.
Intermittent operating life
1037
Electrical measurements
See table I, subgroup 2
Subgroup 4
RΘJSP can be calculated but shall be measured once in
* Thermal resistance
4081
n = 15, c = 0
the same package with a similar die size to confirm
calculations (may apply to multiple specification sheets).
Thermal impedance
See MIL-PRF-19500, table E-IX, group E, subgroup 4.
Sample size
curves
N/A
Subgroup 5
Not applicable
11 devices
Subgroup 6
ESD
1020
n = 45
Subgroup 8
Resistance to glass
1057
Test condition B. Test until failure occurs or to a
cracking
maximum of 25 cycles, whichever comes first.
Not required for UB suffix devices
Subgroup 9
Monitored mission
1055
Not required for UB suffix devices
n = 22, c = 0
temperature cycling
Electrical measurements
See table I, subgroup 2
16
