MIL-PRF-19500/296F
TABLE II. Groups B, C, and E electrical measurements. 1/ 2/ 3/
Step
Inspection
Symbol
Limit
Unit
Method
Conditions
Min
Max
1
Gate reverse current
3411
Bias condition C; VGS = 15 V dc;
23
nA dc
IGSS1
VDS = 0
2
Gate reverse current
3411
Bias condition C; VGS = 15 V dc;
45
nA dc
IGSS2
VDS = 0
3
Drain current
3413
Bias condition C; VGS = 5 V dc;
-2.0
-10.0
mA dc
IDSS1
VDS = 0
4
Drain current
3413
Bias condition C; VGS = 5 V dc;
-1.80
-11.0
mA dc
IDSS2
VDS = 0
5
Small-signal, common-
3455
VDS = 5 V dc; VGS = 0;
µmho
Yfs1
source short-circuit,
f = 1 kHz
2,000
6,250
forward transfer
admittance
6
Small-signal, common-
3455
VDS = 5 V dc; VGS = 0;
µmho
Yfs3
source short-circuit,
f = 1 kHz
1,800
6,875
forward transfer
admittance
1/ The electrical measurements for table E-VIB (JAN) of MIL-PRF-19500 are as follows:
a. Subgroup 2, see table II herein, steps 1, 3, and 5.
b. Subgroups 3 and 6, see table II herein, steps 2, 4, and 6.
2/ The electrical measurements for table E-VII of MIL-PRF-19500 are as follows:
a. Subgroups 2 and 3, see table II herein, steps 1, 3, and 5.
b. Subgroup 6, see table II herein, steps 2, 4, and 6.
3/ The electrical measurements for table E-IX of MIL-PRF-19500 are: Subgroups 1 and 2, see table II herein, all
steps.
