MIL-PRF-19500/211D
Dimensions
Letter
Inches
Millimeters
Notes
Min
Max
Min
Max
NOTES:
1. Dimensions are in inches. Millimeters are given for
A
1.520
38.10
4
general information only.
B
.530
.755
13.46
19.18
2. Complete threads to extend to within 2.5 threads of
seating plane.
C
.063
.172
1.60
4.37
3. .750-16 UNF-2A. Maximum pitch diameter of plated
φD
threads shall be basic pitch diameter, .7094 inch (18.019
1.100
27.94
mm) ref. (Screw Thread Standards for Federal Services)
φD1
.600
15.24
FED-STD-H28.
4. Angular orientation of terminal and tabulation with respect
to hex base is undefined. Square or radius on end of
E
1.218
1.252
30.94
31.75
terminal is undefined.
F
.250
.562
6.35
14.27
5
5. A chamfer (or undercut) on one, or both, ends of
hexagonal portions is optional.
H
5.125
6.750
130.18
171.45
6. Tabulation optional.
.375
9.53
7
I1
7. Minimum flat.
8. Flexible leads.
φM
.660
.745
16.76
18.92
2
.125
3.18
6
M1
N
.793
.828
20.14
21.03
Q
2.300
57.15
Q1
.375
9.53
6
φt
.265
.350
6.73
3.89
W
3
FIGURE 1. Physical dimensions for semiconductor devices.
4
