MIL-PRF-19500/295F
CERAMIC
Dimensions
Dimensions
Symbol
Note
Symbol
Note
Inches
Millimeters
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
BH
.046
.056
1.17
1.42
LS1
.035
.040
0.89
1.02
BL
.115
.128
2.92
3.25
LS2
.071
.079
1.81
2.01
BW
.085
.108
2.16
2.74
LW
.016
.024
0.41
0.61
CL
.128
3.25
r
.008
0.20
CW
.108
2.74
r1
.012
0.31
LL1
.022
.038
0.56
0.96
r2
.022
0.56
LL2
.017
.035
0.43
0.89
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Hatched areas on package denote metallized areas.
4. Lid material: Kovar.
5. Pad 1 = Drain, Pad 2 = Source, Pad 3 = Gate, Pad 4 = Shielding connected to the lid.
6. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.
* FIGURE 2. Physical dimensions, surface mount, 2N2608UB.
