MIL-PRF-19500/297H

TABLE III. Groups B, C, and E delta electrical end-point measurements. 1/ 2/ 3/

MIL-STD-750

Limits

Step

Inspection

Symbol

Unit

Method

Conditions

Min

Max

ĆVF2

Forward voltage

4011

�50 mV dc maximum

IF =110 a(pk) dc tp < 8.3 ms,

change from previous

duty cycle < 2 percent pulse.

measured value.

ĆIR1 4/

Reverse current

4016

DC method, VR = Rated VR(dc)

�100 percent of initial value

or �5.0 �A, (whichever is

(see 1.3)

greater) from previous

measured value.

1/ The delta electrical measurements for table VIb (JAN, JANTX and JANTXV) of MIL-PRF-19500 are as follows:

a. Subgroup 2, see table III herein, step 1.

b. Subgroup 3 see table III herein, steps 1 and 2.

2/ The delta electrical measurements for table VII of MIL-PRF-19500 are as follows:

a. Subgroup 2 see table III herein, step 1 (JAN, JANTX and JANTXV).

b. Subgroup 6, see table III herein, steps 1 and 2 (JAN, JANTX and JANTXV).

3/ The delta electrical measurements for table IX of MIL-PRF-19500 are as follows:

a. Subgroup 1 see table III herein, step 1.

b. Subgroup 2, see table III herein, step 2.

4/ Devices which exceed the table I limits for this test shall be rejected.
