INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/466C
shall be completed by 13 June 2007.
13 March 2007
SUPERSEDING
MIL-PRF-19500/466B
19 July 1999
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, POWER,
TYPES 2N5683 AND 2N5684, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, silicon, power transistors. Three
levels of product assurance are provided for each device type as specified in MIL-PRF19500.
1.2 Physical dimensions. See figure 1 (similar to TO-3).
* 1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
VEBO
IB
IC
TJ and TSTG
VCBO
PT (1)
VCEO
Types
RθJC
TC = +25°C TC = +100°C
°C/W
°C
W
W
V dc
A dc
A dc
V dc
V dc
2N5683
300
171
60
5
15
50
60
.584
-65 to +200
2N5684
300
171
80
5
15
50
80
.584
-65 to +200
(1) Between TC = +25°C and TC = +200°C, linear derating factor (average) = 1.715 W/°C.
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
