The documentation and process conversion measures
INCH-POUND
necessary to comply with this document shall be
completed by 13 February 2014.
MIL-PRF-19500/525F
13 December 2013
SUPERSEDING
MIL-PRF-19500/525E
1 October 2009
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER
TYPES 2N6546, 2N6546T1, 2N6546T3, 2N6547, 2N6547T1,
AND 2N6547T3 JAN, JANTX, JANTXV6 AND JANHC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, power transistors. Three
levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (TO-3), figure 2 (TO-254), figure 3 (TO-257) and figure 4 (JANHCA).
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
PT (1)
VCEX
Limits
VCEO
VEBO
IB
IC
TJ and TSTG
RθJC
(2)
TC = +25°C
TC = +100°C
°C
°C/W
W
W
V dc
V dc
V dc
A dc
A dc
2N6546
175
100
600
300
8
10
15
-65 to +200
1.0
2N6546T1
175
100
600
300
8
10
15
-65 to +200
1.0
2N6546T3
125
100
600
300
8
10
15
-65 to +200
1.4
2N6547
175
100
850
400
8
10
15
-65 to +200
1.0
2N6547T1
175
100
850
400
8
10
15
-65 to +200
1.0
2N6547T3
125
100
850
400
8
10
15
-65 to +200
1.4
(1) See figure 5 for derating curves.
(2) See figures 6, 7, and 8 for thermal impedance graphs.
