MIL-PRF-19500/525F
TABLE I. Group A inspection - Continued.
MIL-STD-750
Limits
Symbol
Unit
Inspection 1/
Method
Conditions
Min
Max
Subgroup 3
TA = +150°C
High temperature operation:
Collector to emitter cutoff
3041
Bias condition A;
ICEX2
30
mA dc
current
VBE = 1.5 V dc
2N6546, 2N6546T1, 2N6546T3
VCE = 600 V dc
2N6547, 2N6547T1, 2N6547T3
VCE = 850 V dc
µA dc
Collector to emitter cutoff
3041
Bias condition A;
ICEX3
450
current
VBE = 1.5 V dc;
VCE = 300 V dc
2N6546, 2N6546T1, 2N6546T3
VCE = 400 V dc
2N6547, 2N6547T1, 2N6547T3
TA = -55°C
Low temperature operation:
Forward-current
3076
VCE = 2.0 V dc; IC = 5 A
hFE4
4
transfer current
dc; pulsed (see 4.5.1)
Subgroup 4
Pulse response
3251
Test condition A except
test circuit and pulse
requirements in
accordance with figure 9
herein.
µs
Turn-on time
VCC = 250 V dc;
ton
1.0
IC = 10 A dc;
IB1 = IB2 = 2 A dc
µs
Turn-off time
VCC = 250 V dc;
toff
4.7
IC = 10 A dc;
IB1 = IB2 = 2 A dc
hfe
Magnitude of common
3306
VCE = 10 V dc;
6.0
30
emitter small-signal
IC = .5 A dc;
short-circuit forward-
f = 1 MHz
current transfer ratio
Output capacitance
3236
VCB = 10 V dc; IE = 0;
Cobo
500
pF
0.1 MHz ≤ f ≤ 1.0 MHz
(open circuit)
