MIL-PRF-19500/582B
30 January 2009
SUPERSEDING
MIL-PRF-19500/582A
21 August 1999
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON AMPLIFIER,
TYPES 2N5679 AND 2N5680, JAN, JANTX AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, silicon, amplifier transistor. Three
levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1, (TO-39).
* 1.3 Maximum ratings. Unless otherwise specified, TA = +25C.
RJC
Type
PT (1)
PT
VCBO
VCEO
VEBO
IC
IB
TJ and TSTG
TA = +25C TC = +25C
(2)
C
C
V dc
W
W
V dc
V dc
A dc
A dc
17.5
2N5679
1.0
10
100
100
4.0
1.0
0.5
-65 to +200
17.5
2N5680
1.0
10
120
120
4.0
1.0
0.5
(1) Derate linearly 5.7 mW/C for TA > +25C;
(2) Derate linearly 57mW/C for TC > +25C.
1.4 Primary electrical characteristics at TA = +25C.
hFE at VCE = 2.0 V dc (1)
VCE(sat)1 (1) VBE(sat)1 (1)
Cobo
/hfe /
Limits
f = 1.0 MHz
f = 10 MHz
IC = 250 mA dc IC = 250 mA dc
hFE1
hFE3
hFE2
VCB = 20 V dc IB = 25 mA dc IB = 25 mA dc
VCE = 10 V dc
IC = 1.0 A dc
IC = 250 mA dc IC = 500 mA dc
IE = 0
IC = 100 mA dc
V dc
pF
Min
40
20
5
3.0
Max
150
50
1.1
0.6
(1) Pulsed see 4.5.1.
