MIL-PRF-19500/594B
* TABLE III. Group B, C, and E delta requirements. 1/ 2/ 3/ 4/ 5/
Step
Inspection
MIL-STD-750
Symbol
Limit
Unit
Method
Conditions
Duty cycle ≤ 2 percent
1.
Forward voltage
4011
(pulsed see 4.5.1); tp =
8.3 ms (max)
±50 mV dc change
ĆVF1
1N6664,R,
IF = 6 A
1N6665, R,
from initial value
1N6666, R
ĆVF2
±50 mV dc change
1N6664, R,
IF = 12 A
1N6665, R,
from initial value
1N6666, R
ĆIR1
2.
Reverse current
4016
DC method
100 percent or ±150
1N6664, R,
VR = 100 V dc
1N6665, R,
VR = 150 V dc
nA dc change from
initial reading,
1N6666, R
VR = 200 V dc
whichever is greater
1/
Devices which exceed the table I limits for this test shall not be accepted.
2/
The electrical measurements for group B inspections in table E-VIa (JANS) of MIL-PRF-19500 are as follows:
Subgroups 4 and 5, see table III herein, steps 1 and 2.
3/
The electrical measurements for group B inspections in table E-VIb (JAN, JANTX, and JANTXV) of
MIL-PRF-19500 are as follows: Subgroup 3, see table III herein, steps 1 and 2.
4/
The electrical measurements for group C inspections in table E-VII (all quality levels) of MIL-PRF-19500 are as
follows: Subgroup 6, see table III herein, steps 1 and 2.
5/
The electrical measurements for group E inspections in table E-IX of MIL-PRF-19500 are as follows:
Subgroups 1 and 2, see table III herein, steps 1 and 2.
10
