MIL-PRF-19500/594B

* TABLE II. Group E inspection (all quality levels) for qualification only.

Inspection

MIL-STD-750

Sampling plan

Method

Conditions

Subgroup 1

45 devices

c=0

20 cycles, except high temperature shall be 100�C and low

Thermal shock

1056

temperature shall be 0�C.

(liquid to liquid)

500 cycles, condition C. -65�C to +200�C.

Temperature

1051

cycling (air to air)

Hermetic seal

1071

Electrical

See table I, group A, subgroup 2 and table III,

measurement

steps 1 and 2.

Subgroup 2

22 devices

c=0

Test condition A, t = 1,000 hours, TC = +150�C,

Steady-state

1038

reverse bias

VR = 0.8 of rated VRWM (see 1.3).

Electrical

See table I, group A, subgroup 2 and table III, steps 1 and

measurement

Subgroup 3

Not applicable

Subgroup 4

Sample size

N/A

Thermal

See MIL-PRF-19500.

impedance

curves

See footnotes at end of table
