MIL-PRF-19500/157T

1.4 Primary electrical characteristics. Unless otherwise specified, primary electrical characteristics at TA = +25C.

VZ

(1)

(voltage -temperature

Type

VR = 8.0 V

(1)

stability)

Min

Max

(1)

A

mV dc

ohms

volts

1N941B-1, 1N941BUR-1

239.0

11.12

12.28

15.0

1N943B-1, 1N943BUR-1

47.0

11.12

12.28

15.0

1N944B-1, 1N944BUR-1

24.0

11.12

12.28

15.0

1N945B-1, 1N945BUR-1

12.0

11.12

12.28

15.0

1N946B-1, 1N946BUR-1

4.7

11.12

12.28

15.0

(1) To guarantee voltage temperature stability, it is necessary to maintain an IZ of 7.5 mA dc.

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This

section does not include documents cited in other sections of this specification or recommended for additional

information or as examples. While every effort has been made to ensure the completeness of this list, document

users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this

specification, whether or not they are listed.

2.2 Government documents.

2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a

part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are

those cited in the solicitation or contract.

DEPARTMENT OF DEFENSE SPECIFICATIONS

MIL-PRF-19500

Semiconductor Devices, General Specification for.

DEPARTMENT OF DEFENSE STANDARDS

MIL-STD-750

Test Methods for Semiconductor Devices.

(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or

https://assist.daps.dla.mil or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D,

Philadelphia, PA 19111-5094.)

* 2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the

text of this document and the references cited herein, the text of this document takes precedence. Nothing in this

document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.

3. REQUIREMENTS

3.1 General. The individual item requirements shall be as specified in MIL-PRF-19500 and as modified herein.

3.2 Qualification. Devices furnished under this specification shall be products that are manufactured by a

manufacturer authorized by the qualifying activity for listing on the applicable qualified manufacturer's list (QML)

before contract award (see 4.2 and 6.3).

3.3 Abbreviations, symbols, and definitions. The abbreviations, symbols, and definitions used herein shall be as

specified in MIL-PRF-19500.
