MIL-PRF-19500/181J
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Limit
Unit
Symbol
Method
Conditions
Min
Max
Subgroup 4 Continued
-4
Small signal open circuit
3211
VCB = 10 V dc, f = 1 kHz,
3 x 10
hrb
reverse voltage transfer
IC = 5 mA dc
ratio
Open circuit output
3236
25
pF
VCB = 10 V dc, IE = 0,
Cobo
100 kHz ≤ f ≤ 1 MHz
capacitance
Pulse response
3251
Test condition A, except test circuit
30
ns
ton + toff
and pulse requirements.
See figure 5 herein.
Subgroups 5 and 6
Not applicable
1/ For sampling plan, see MIL-PRF-19500.
*
2/ For resubmission of failed subgroup 1, double the sample size of the failed test or sequence of tests. A failure
in table I, subgroup 1 shall not require retest of the entire subgroup. Only the failed test shall be rerun upon
submission.
3/ Separate samples may be used.
4/ Not required for laser marked devices.
11
