INCH-POUND
MIL-PRF-19500/199D
14 August 2006
SUPERSEDING
MIL-PRF-19500/199C
25 February 2004
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON,
FORWARD-VOLTAGE REGULATOR,
TYPE 1N816, JAN
MIL-PRF-19500/199 is inactive for new design as of 7 June 1999.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, forward-voltage regulator, with a
nominal forward-voltage drop of 0.64 V dc at 1 mA dc and with the following ratings and characteristics. One level of
product assurance is provided for each type of device type as specified in MIL-PRF-19500.
* 1.2 Physical dimensions. See figure 1 (DO-35, DO-7).
1.3 Maximum ratings.
Vr
VRM(wkg)
IF
If(surge)
TJ
TSTG
1/120 sec
V(pk)
V(pk)
mA dc
mA dc
-65°C to 150°C -65°C to 175°C
10
6
150
500
RΘJL = 250°C/W (maximum) at L = .375 inch (9.53 mm) mounting conditions.
RΘJA = 300°C/W. Junction to ambient including PCB.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of
AMSC N/A
FSC 5961
For Parts Inquires call Parts Hangar, Inc (727) 493-0744
