MIL-PRF-19500-199 Semiconductor Device, Diode, Silicon, Forward-Voltage Regulator, Type 1N816, JanThis specification covers the performance requirements for silicon, forward-voltage regulator, with a nominal forward-voltage drop of 0.64 V dc at 1 mA dc and with the following ratings and characteristics. One level of product assurance is provided for each type of device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8

MIL-PRF-19500/199D

Dimensions

Types

Symbol

Inches

Millimeters

Min

Max

Min

Max

.056

.075

1.42

1.91

.140

.180

3.56

4.57

(DO-35)

.018

.022

0.46

0.56

1.000

1.500

25.40

38.10

.078

.107

1.98

2.72

.195

.300

4.95

7.62

(DO-7)

.018

.022

0.46

0.56

1.000

1.500

25.40

38.10

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. In accordance with ASME Y14.5M, diameters are equivalent to Φx symbology.

* FIGURE 1. Physical dimensions (DO-35, DO-7).
