MIL-PRF-19500/302C
For information purposes
Input levels (Vcb):
4.0 MHz = 400 mV
46.0 MHz = 346 mV
10.7 MHz = 471 mV
50.0 MHz = 318.4 mV
31.8 MHz = 500 mV
63.6 MHz = 250 mV
40.0 MHz = 400 mV
79.8 MHz = 200 mV
INTERPRETATION OF READINGS:
rb'Cc range (psec)
Meter range full scale
31.8, 40.0, 46.0, 50.0
4.0 MHz
10.7 MHz
63.6, 79.8 MHz
31.6
100 psec
10 psec
0.001 volt
100.0
300 psec
30 psec
0.003 volt
316.0
1000 psec
100 psec
0.01 volt
1000.0
300 psec
0.03 volt
1000 psec
0.1 volt
FIGURE 3. Collector-base time constant test circuit (an equivalent circuit may be used). - Continued.
