MIL-PRF-19500/358F

* 4.3 Screening (JANS, JANTXV, and JANTX levels only). Screening shall be in accordance with table E-IV of

MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I

herein. Devices that exceed the limits of table I herein shall not be acceptable.

Screen

Measurement

(see table E-IV of

JANS level

JANTX and JANTXV levels

MIL-PRF-19500)

(1) 3C

Thermal impedance, see 4.3.2.

IR1 and VZ (for devices with VZ (nom) ≥ 10 V dc;

Not applicable.

see column 1 of table III).

IR1 and VZ; ĆIR1 = 100 percent of initial value or

2 �A dc, whichever is greater; ĆVZ = �1 percent of

IR1 and VZ

initial value (for devices with VZ(nom) ≥ 10 V dc;

see column 2 of table III).

See 4.3.1.

Subgroup 2 (except forward voltage test) and

Subgroup 2 (except forward voltage test)

subgroup 3 of table I herein; ĆIR1 = 100 percent of

of table I herein; ĆIR1 = 100 percent of

initial value or 2 �A dc, whichever is greater, ĆVZ

initial value or 2 �A dc, whichever is

greater, ĆVZ = �1 percent of initial value.

= �1 percent of initial value.

* (1) This test shall be performed anytime after screen 3.

* 4.3.1 Power burn-in conditions. Power burn-in conditions are as follows: IZ: Column 4 of table III at TJ = 150�C

minimum.

* 4.3.2 Thermal impedance. The thermal impedance measurements shall be performed in accordance with method

3101 or 4081 of MIL-STD-750, as applicable, using the guidelines in that method for determining IM, IH, tH, tSW (VC

and VH where appropriate). Measurement delay time (tMD) = 70 �s max.

4.4 Conformance inspection. Conformance inspection shall be in accordance with MIL-PRF-19500 and as

specified herein. Group A inspection shall be performed on each sublot.

4.4.1 Group A inspection. Group A inspection shall be conducted in accordance with MIL-PRF-19500 and table I

herein. Electrical measurements (end-points) shall be in accordance with table I, subgroup 2 herein.

4.4.2 Group B inspection. Group B inspection shall be conducted in accordance with the tests and conditions

specified for subgroup testing in table E-VIa (JANS) and table E-VIb (JAN, JANTX, and JANTXV) of MIL-PRF-19500

and herein. Electrical measurements (end-points) shall be in accordance with table I, subgroup 2 herein. Delta

measurements shall be in accordance with table II herein.
