MIL-PRF-19500/385H
* TABLE I. Group A inspection - Continued.
Inspection 1/ 2/
Symbol
Unit
MIL-STD-750
Limits
Method
Conditions
Min
Max
Subgroup 3
TA = +150C
High temperature operation:
Bias condition C; VDS = 0 V
IGSS2
Gate reverse current
3411
A dc
2N4856, 2N4857, 2N4858
-0.5
VGS = -20 V dc
A dc
VGS = -15 V dc
2N4859, 2N4860, 2N4861
-0.5
A dc
Bias condition A, VDS = 15 V
Drain current
3413
0.5
ID(off)2
dc; VGS = -10 V dc
Subgroup 4
Small-signal common-source
3431
18
pF
VDS = 0, VGS = -10 V;
Ciss
short-circuit input capacitance
f = 1 MHz; C1 = .1 F,
C 2= 20.1 F
L1 = L2 = 500 H
Small-signal common-source
8
pF
3433
VDS = 0, VGS = -10 V;
Crss
short-circuit reverse transfer
f = 1 MHz; C1 = .1 F,
capacitance
L1 = L2 = 500 H
td(on)
Turn-on delay time
3459
See figure 3
2N4856, 2N4859
6
ns
2N4857, 2N4860
6
ns
2N4858, 2N4861
10
ns
Rise time
3459
See figure 3
tr
2N4856, 2N4859
3
ns
2N4857, 2N4860
4
ns
2N4858, 2N4861
10
ns
td(off)
Turn-off delay time
3459
See figure 3
2N4856, 2N4859
25
ns
2N4857, 2N4860
50
ns
2N4858, 2N4861
100
ns
Subgroups 5, 6, and 7
Not applicable
1/ For sampling plan, see MIL-PRF-19500.
2/ These characteristics applicable to all package styles, unless otherwise noted.
