MIL-PRF-19500/412F

TABLE I. Group A inspection - Continued.

MIL-STD-750

Limits

Symbol

Unit

Inspection 1/

Method

Conditions

Min

Max

Subgroup 5 - Continued.

3005

Burnout by pulsing (safe

TC = +100�C; pre-pulse condition:

(3051)

operating area - dc)

see figure 9, VCE = 300 V dc,

2N3847, 2N3847T1, 2N3847T3

IC = 20 mA dc, tp = 1.0 s, 1 cycle, (T1

only

and T3 may require heatsink).

Unclamped inductive sweep

TC = +100�C, IB = 2 A dc, IC = 20 A dc,

see figure 10

Clamped inductive sweep

TC = +100�C, IB = 2 A dc, IC = 20 A dc,

see figure 11

End-point electrical

See table I, subgroup 2 herein

measurements

Subgroups 6 and 7

Not applicable

For sampling plan, see MIL-PRF-19500.

This test required for the following end-point measurements only:

Group B, subgroups 3, 4, and 5 (JANS).

Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).

Group C, subgroup 2 and 6.

Group E, subgroup 1.
