MIL-PRF-19500/412F
TABLE II. Group E inspection (all quality levels) - for qualification only.
MIL-STD-750
Inspection
Qualification
Method
Conditions
Subgroup 1
45 devices
c=0
Thermal shock
1056
0°C to +100°C, 100 cycles
glass strain
Hermetic seal
1071
Fine leak
Gross leak
Electrical measurements
See table I, subgroup 2 herein.
Subgroup 2
45 devices
c=0
Steady-state dc blocking life
1039
1,000 hours
or
1048
Electrical measurements
See table I, subgroup 2 herein.
Subgroup 4
Sample size
N/A
Thermal impedance curves
See MIL-PRF-19500.
Subgroup 5
3 devices,
c=0
Barometric pressure
1001
Pressure = 8.0 mm Hg time = 60 seconds; normal mounting
Subgroup 8
45 devices
c=0
Reverse stability
1033
Condition A for devices ≥ 400 V,
Condition B for devices < 400 V.
13
