MIL-PRF-19500/446E
* 4.3.2 Assembly screening. One hundred percent of the completed assemblies shall be subjected to the following.
Screen
(see table E-IV of
Measurement
MIL-PRF-19500)
Temperature cycling
Method 1051 of MIL-STD-750, condition F.
End points (1)
Subgroup 2 of table I herein.
Dielectric withstanding voltage
See 4.5.1
(1) Except thermal impedance.
4.4 Conformance inspection. Conformance inspection shall be performed on the finished rectifier assemblies in
accordance with MIL-PRF-19500 and as specified herein.
4.4.1 Group A inspection. Group A inspection shall be conducted in accordance with table E-V of MIL-PRF-19500
and table I herein.
* 4.4.2 Group B inspection. Group B inspection shall be conducted in accordance with the conditions specified for
subgroup testing in table E-VIB (JANTX and JANTXV) of MIL-PRF-19500 and as follows. Electrical measurements
(end-points) shall be in accordance with table I, group A, subgroup 2 (except thermal impedance) herein.
* 4.4.2.1 Group B inspection, table E-VIB of MIL-PRF-19500.
Subgroup
Method
Conditions
B1
2026
Immerse to insulating sleeve.
B2
1051
Condition F, 25 cycles.
B2
1071
Not applicable.
IO = 0 A dc; TA = +150C; VRWM = 80 percent rated VRWM (see 1.3), f = 60 Hz,
B3
1027
n = 10, c = 0.
B5
Operational thermal cycling, (see 4.5.4).
B5
3105
Junction temperature test (see 4.5.2).
B6
Not applicable.
4.4.3 Group C inspection. Group C inspection shall be conducted in accordance with the conditions specified for
subgroup testing in table E-VII of MIL-PRF-19500, and as follows. Electrical measurements (end-points) shall be in
accordance with table I, group A, subgroup 2 (except thermal impedance) herein.
5
