INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/467A
shall be completed by 23 August 2008.
23 April 2008
SUPERSEDING
MIL-S-19500/467
25 January 1972
* PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, LIGHT EMITTING,
TYPE 1N5765 JAN AND TX
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
* The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
* 1.1 Scope. This specification covers the performance requirements for hermetically-sealed, red light emitting
diodes. Two levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1.
* 1.3 Maximum ratings. Unless otherwise specified TA = +25°C.
BV
IF (1)
PT
Ip (2)
TOP and
TJ
TSTG
°C
°C
mA dc
mW
A (pk)
V dc
4
50
150
3.0
-65 to +100
-65 to +120
(1) Derate 0.67 mAdc/°C for TA above 25°C.
(2) 1 μs pulse width, 300 pps.
* 1.4 Characteristics, radiometric (physical), and photometric (visual).
λV
IV1
IV2
VF
IR
C
VR = 0
Color
IF = 20 mA dc
IF = 20 mA dc IF = 20 mA dc
VR = 3 V
(wave
Limits
f = 1 MHz
Θ = 0 degrees
Θ = 30 degrees
length)
μA dc
mcd
mcd
V dc
nm
pF
Red
630
---
0.3
---
0.5
Min
700
300
1
2.0
3.0
Max
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
semiconductor@dscc.dla.mil . Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
