MIL-PRF-19500/483D
shall be completed by 2 July 2009.
2 April 2009
SUPERSEDING
MIL-PRF-19500/483C
16 November 2006
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, SILICON, HIGH-POWER,
THREE PHASE, FULL WAVE BRIDGE RECTIFIER,
TYPES M19500/483-01 THROUGH M19500/483-04, JANTX
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, 3-phase, full wave bridge rectifiers
intended for use in applications at frequencies of 1 kHz or less. One level of product assurance is provided for each
device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1.
1.3 Maximum ratings. Unless otherwise specified TA = +25C.
TJ
TSTG
IF(surge) Barometric
VRWM Bridge (1) Bridge (2)
Types
pressure
IO = IO1
(reduced)
IO2 at
IO1 at
TC = +55C
TC = +55C
TC =
tp = 8.3 ms
+100C
C
C
M19500/483-
V (pk)
A dc
A dc
A (pk)
mmHg
01
200
25
18.5
150
8
-65C to
-65C to
02
400
25
18.5
150
8
+175C
+150C
03
600
25
18.5
150
33
04
800
25
18.5
150
33
(1) Derate from 25 A dc at TC = +55C to 18.5 A dc at TC = +100C (144 mA dc/C).
(2) Derate from 18.5 A dc at TC +100C to 0 A dc at TC = +150C (370 mA dc/C).
