MIL-PRF-19500-483 Semiconductor Device, Silicon, High-Power, Three Phase, Full Wave Bridge Rectifier, Types M19500/483-01 Through M19500/483-04, JantxThis specification covers the performance requirements for silicon, 3-phase, full wave bridge rectifiers intended for use in applications at frequencies of 1 kHz or less. One level of product assurance is provided for each device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/483D
Dimensions
Inches
Millimeters
Inches
Millimeters
Ltr
Ltr
Min
Max
Min
Max
Min
Max
Min
Max
L1
A
.710
.770
18.03
19.56
.130
.320
3.30
8.13
L2
B
.355
.395
9.02
10.03
.015
.030
0.38
0.76
L3
C
.355
.395
9.02
10.03
.100
.125
2.54
3.18
D1
.141
.151
3.58
3.84
M
.040
.060
1.02
1.52
.108
.118
2.74
3.00
N
.720
.780
18.29
19.81
D2
E
.355
.395
9.02
10.03
O
1.84
1.90
46.74
48.26
F
.230
.270
5.84
6.86
P
2.22
2.28
56.39
57.91
G
.149
.189
3.78
4.80
R
.090
.150
2.29
3.81
H
.355
.395
9.02
10.03
S
.168
.208
4.27
5.28
J
.820
20.83
T
1.47
1.53
37.34
38.86
K
.390
.590
9.91
14.99
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Polarity shall be marked as shown on drawing.
4. Point at which TC is read shall be in metal part of case as shown on drawing.
5. In accordance with ASME Y14.5M, diameters are equivalent to x symbology.
FIGURE 1. Physical dimensions.
