MIL-PRF-19500/483D
3.4.3 Parallel diode construction. For bridge design that employs more than one diode for each leg and N equals
the number of diodes for each leg, the following design and matching conditions shall be approved by the qualifying
activity.
a. Individual diode room temperature VF matching shall be performed at a current value of (IO1/N) or
greater. The VF shall be within 20 mV on each diode.
b. The same diode design shall be used in each parallel leg.
c. The design shall ensure similar lead lengths and uniform heat paths, so that all diodes in each leg are at
similar junction temperatures.
3.5 Marking. Marking shall be in accordance with MIL-PRF-19500.
3.5.1 Polarity. Polarity shall be as marked on figure 1.
3.6 Electrical performance characteristics. Unless otherwise specified herein, the electrical performance
characteristics are as specified in 1.3 and table I.
3.7 Electrical test requirements. The electrical test requirements shall be the subgroups specified in table I herein.
3.8 Workmanship. Semiconductor devices shall be processed in such a manner as to be uniform in quality and
shall be free from other defects that will affect life, serviceability, or appearance.
4. VERIFICATION
4.1 Classification of Inspections. The inspection requirements specified herein are classified as follows:
a. Qualification inspection (see 4.2).
b. Screening (see 4.3).
c. Conformance inspection (see 4.4).
4.2 Qualification inspection. Qualification inspection shall be in accordance with MIL-PRF-19500 and as specified
herein.
4.3 Screening (JANTX level). Screening shall be in accordance with table E-IV of MIL-PRF-19500, and as
specified herein. The following measurements shall be made in accordance with table I herein. Devices that exceed
the limits of table I, subgroup 2 herein, and 4.3.1.1 herein shall not be acceptable.
4.3.1 Discrete diode screening. One hundred percent of the internal discrete diodes shall be subjected to the
following:
Screen
Measurement
(see table E-IV of
MIL-PRF-19500)
JANTX level
3c
Method 3101 of MIL-STD-750 (see 4.3.1.1)
9
Not applicable
11
VF at IF/N and IR2/N of subgroup 2 of table I herein
12
See 4.3.1.2
13
VF at IF/N and IR2/N of subgroup 2 of table I herein.
VF1/n = ±0.05 V dc; IR2 = 100 percent of initial value or ±250 nA dc,
whichever is greater. Scope display evaluation (see 4.5.3)
4
