MIL-PRF-19500/498E
* 1.4 Primary electrical characteristics. TA = +25°C, unless otherwise specified.
VBE(sat) (1)
VCE(sat)1 (1)
VCE(sat)2 (1)
hFE2
hFE1
Type
VCE = 5 V dc
VCE = 5 V dc
IC = 8 A dc
IC = 8 A dc
IC = 3 A dc
IC = 3 A dc
IC = 8 A dc
IB = (2)
IB = (2)
IB = 0.6 A dc
Max
Min
Max
Min
Max
Min
Max
Min
Max
Min
V dc
V dc
V dc
V dc
V dc
V dc
2N6306
15
75
4
2.3
5
0.8
2N6306T1
15
75
4
2.3
5
0.8
2N6306T3
15
75
4
2.3
5
0.8
2N6308
12
60
3
2.5
5
1.5
2N6308T1
12
60
3
2.5
5
1.5
2N6308T3
12
60
3
2.5
5
1.5
|hfe|
Cobo
Switching (3)
VCB = 10 V dc
VCE = 10 V dc
Limit
IC = 0.3 A dc
IE = 0
ton
toff
100 kHz ≤ f ≤ 1 MHz
f = 1 MHz
µs
µs
pF
5
Min
30
Max
250
0.6
3.0
(1) Pulsed (see 4.5.1).
(2) 2N6306, 2N6306T1, 2N6306T3 (IB) = 2.0 A dc; 2N6308, 2N6308T1, 2N6308T3 (IB) = 2.67 A dc.
* (3) See figure 10 (pulse response circuit).
2. APPLICABLE DOCUMENTS
* 2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
* 2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
*
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-19500
-
Semiconductor Devices, General Specification for.
*
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-750
-
Test Methods for Semiconductor Devices.
* (Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or
https://assist.daps.dla.mil/ or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D,
Philadelphia, PA 19111-5094.)
2.3 Order of precedence. In the event of a conflict between the text of this specification and the references cited
herein, the text of this specification takes precedence. Nothing in this specification, however, supersedes applicable
laws and regulations unless a specific exemption has been obtained.
2
