MIL-PRF-19500/522A
TABLE I. Group A inspection.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 4 - continued
Noise figure
----
NF
VCE = 10 V dc; IC = 5 mA dc;
f = 1 GHz (see 4.5.2 and figure 3)
2N6603
1.0
2.5
dB
2N6604
1.5
3.0
dB
Subgroups 5 and 6
Not applicable
Subgroup 7
Input reflection coefficient
----
VCE = 10 V dc; f = 1 GHz;
ZO = 50 Ω;
2N6603
/S11/
.5
.8
--
IC = 15 mA dc
°C
L0S11
+165
-165
2N6604
/S11/
.45
.75
--
IC = 30 mA dc
°C
L0S11
+155
-175
Output reflection coefficient
----
VCE = 10 V dc; f = 1 GHz;
ZO = 50 Ω;
2N6603
/S22/
.25
.5
--
IC = 15 mA dc
°C
L0S22
-70
-30
2N6604
/S22/
.2
.4
--
IC = 30 mA dc
°C
L0S22
-70
-30
Forward transfer coefficient
----
VCE = 10 V dc; f = 1 GHz;
ZO = 50 Ω;
2
2N6603
12
--
dB
IC = 15 mA dc
/S21/
2
2N6604
12
--
dB
IC = 30 mA dc
/S21/
Reverse transfer coefficient
----
VCE = 10 V dc; f = 1 GHz;
ZO = 50 Ω;
2
2N6603
--
-22.5
dB
IC = 15 mA dc
/S12/
2
2N6604
--
-22.5
dB
IC = 30 mA dc
/S12/
Power gain at optimum noise
----
6
--
dB
VCE = 10 V dc; IC = 5 mA dc;
GNF
figure
f = 2 GHz (see 4.5.2 and figures 2
and 3)
1/ For sampling plan, see MIL-PRF-19500.
