INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/526H
shall be completed by 2 February 2013.
2 November 2012
SUPERSEDING
MIL-PRF-19500/526G
25 January 2008
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER,
TYPE 2N3879, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, power transistors. Three
levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (TO-66).
1.3 Maximum ratings. (TA = +25°C, unless otherwise specified).
PT (1)
VCBO
VCEO
VEBO
IB
IC
TJ and TSTG
RθJC
TC = +25°C
°C/W
°C
W
V dc
V dc
V dc
A dc
A dc
35
120
75
7
5
7
5
-65 to +200
(1) Derate linearly 200 mW/°C for TC > +25°C.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil/.
AMSC N/A
FSC 5961
