MIL-PRF-19500/526H
Dimensions
Symbol
Notes
Inches
Millimeters
Min
Max
Min
Max
CD
.470
.500
11.94
12.70
3,10
CH
.250
.340
6.35
8.64
HR
.350
8.89
HT
.050
.075
1.27
1.91
HR1
.115
.145
2.92
3.68
8
LD
.028
.034
0.71
0.86
3,7,10
LL
.360
.500
9.14
12.70
3,9
L1
.050
1.27
9
MHD
.142
.152
3.61
3.86
7,10
MHS
.958
.962
24.33
24.43
PS
.190
.210
4.83
5.33
4
PS1
.093
.107
2.36
2.72
4
S
.570
.590
14.48
14.99
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Body contour is optional within zone defined by CD and PS1.
4. These dimensions should be measured at points .050 inch (1.27 mm) .055 inch (1.40 mm)
below seating plane. When gauge is not used measurement will be made at the seating plane.
5. Both terminals.
6. At both ends.
7. Two holes.
8. The collector is electrically connected to the case.
9. LD applies between L1 and LL. Lead diameter shall not exceed twice LD within L1.
10. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.
FIGURE 1. Physical dimensions (TO-66).
3
