INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/544H
shall be completed by 26 November 2014.
SUPERSEDING
26 August 2014
SUPERSEDING
MIL-PRF-19500/544G
12 April 2008
PERFORMANCE SPECIFICATION SHEET
*
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER,
TYPES 2N5152, 2N5154, 2N5152L, 2N5154L, 2N5152U3, 2N5154U3, JAN, JANTX, JANTXV, JANTXVF, JANTXVR,
JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH, JANHCB, JANHCD, JANHCE, JANKCB,
JANKCBF, JANKCD, JANKCE, JANKCDM, JANKCDD, JANKCDP, JANKCDL, JANKCDR, JANKCDF, JANKCDG,
AND JANKCDH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, power transistors for use in
high-speed power-switching applications. Four levels of product assurance are provided for each encapsulated
device type and two levels of product assurance are provided for each unencapsulated device type as specified in
MIL-PRF-19500. RHA level designators "M", "D", "P", "L," "R", "F", "G", and "H" are appended to the device prefix to
identify devices, which have passed RHA requirements.
1.2 Physical dimensions. See figure 1 (similar to TO-5 and TO-39), figures 2, 3, and 4 (die dimensions), and
figure 5 (U3).
1.3 Maximum ratings. Unless otherwise specified TA = +25°C.
*
Type
VCEO
IC
VCBO
Tstg and TJ
VEBO
°C
A dc
V dc
V dc
V dc
2
100
80
5.5
2N5152
2
100
80
5.5
2N5152L
2
100
80
5.5
2N5154
-65 to
2N5154L
2
100
80
5.5
2N5152U3
2
100
80
5.5
+200
2N5154U3
2
100
80
5.5
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil/.
AMSC N/A
FSC 5961
