INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/583B
shall be completed by 22 October 2010.
22 July 2010
SUPERSEDING
MIL-PRF-19500/583A
21 August 1999
*
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON AMPLIFIER,
TYPES 2N5681 AND 2N5682, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN , silicon, amplifier transistor. Three
levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1, (TO-39).
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
RθJC VCBO VCEO
PT
PT
VEBO
IC
IB
Top and TSTG
Type
TA =
TC =
+25°C
+25°C
(1)
(2)
°C
°C
W
V dc
W
V dc
V dc
A dc
A dc
17.5
2N5681
1.0
10
100
100
4.0
1.0
0.5
-65 to +200
17.5
2N5682
1.0
10
120
120
4.0
1.0
0.5
(1) Derate linearly 5.7 mW/°C for TA > +25°C.
(2) Derate linearly 57 mW/°C for TC > +25°C.
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
