MIL-PRF-19500-583 Semiconductor Device, Transistor, Npn, Silicon Amplifier, Types 2N5681 And 2N5682, Jan, Jantx, And JantxvThis specification covers the performance requirements for NPN , silicon, amplifier transistor. Three levels of product assurance are provided for each device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/583B
Symbol
Dimensions
Notes
(see
note 3)
Inches
Millimeters
Min
Max
Min
Max
CD
.305
.335
7.75
8.51
CH
.240
.260
6.10
6.60
HD
.335
.370
8.51
9.39
LC
.200 BSC
5.08 BSC
10
LD
.016
.021
0.41
0.53
10, 11
LL
.500
.750
12.70
19.05
11, 12
LU
.016
.019
0.41
0.48
11, 12
L1
.050
1.27
11, 12
L2
.250
6.35
11, 12
P
.100
2.54
9
Q
.050
1.27
8
R
.010
0.25
13
TL
.029
.045
0.74
1.14
7
TW
.028
.034
0.72
0.86
6
α
45° BSC
10
Term 1
Emitter
Term 2
Base
Term 3
Collector
FIGURE 1. Physical dimensions for (TO-39) continued.
