MIL-PRF-19500P
APPENDIX E
TABLE E-X. Minimum data requirements for JANS devices.1/
JANS data requirements
1.
Wafer lot inspection results (see D.3.9.4.2).
2.
SEM Inspection results and photographs(when applicable, see E.3.1.2.1).
3.
Screening data:
a.  Travelers [Including quantities and dates. Test times (when
applicable). Assembly travelers for screening steps that occur in
assembly].
b.  All recorded electrical data (see E.3.8).
c.  Summary of parts fallout (see E.3.8.1).
d.  Radiograph data (when required and if requested).
4.
Conformance inspection Data [Groups A, B, C. Group D (when
applicable)]:
a.  Travelers [Including quantities and dates. Test times (when
applicable)].
b.  All specified electrical data.
1/ These data requirements do not require the manufacturer to provide the required data unless specified in the
order. The customer may specify additional data requirements in their order.
