MIL�PRF�19500/114H

TABLE II. Groups A, B, and C delta electrical measurements. 1/ 2/

Limits

Step

Inspection

Symbol

Unit

Method

Conditions

Min

Max

ĆVF 3/

Forward voltage

4011

IF = 10 A dc

�50 mV dc

change from

previously

measured value.

The delta electrical measurements for table E�VIa (JANS) of MIL�PRF�19500 shall be as follows:

a. In addition to the measurements specified for subgroup 3, the measurements of step 1 of this table shall

also be taken.

b. In addition to the measurements specified for subgroup 4, the measurements of step 1 of this table shall

also be taken.

c. In addition to the measurements specified for subgroup 5, the measurements of steps 1 of this table shall

also be taken.

2/ The delta electrical measurements for table E�VII of MIL�PRF�19500 shall be as follows:

a. In addition to the measurements specified for subgroup 2, the measurements of step 1 (JANS) of this table

shall also be taken.

b. In addition to the measurements specified for subgroup 3, the measurements of step 1 (JANS) of this table

shall also be taken.

c. In addition to the measurements specified for subgroup 6, the measurements of step 1 of this table shall

also be taken.

3/ Devices which exceed the group A limits for this test shall not be accepted.
