MIL-PRF-19500/162E
completed by 2 December 2014.
2 September 2014
SUPERSEDING
MIL-PRF-19500/162D
2 October 2007
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICES, DIODE, SILICON, POWER RECTIFIER,
TYPES 1N1614, 1N1615, 1N1616, 1N4458, 1N4459, 1N1614R, 1N1615R, 1N1616R,
1N4458R, 1N4459R, JAN AND JANTX
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, power rectifier diodes. Two levels
of product assurance are provided for each device as specified in MIL-PRF-19500.
1.2 Reverse types, (suffix R). Reverse and standard types are identical except: The standard types have the
cathode connected to the stud; the reverse types have the anode connected to the stud. Designated values are
applicable to both types. Reversed (anode to stud) units will be marked with an R following the last digit in the type
number.
1.3 Physical dimensions. See figure 1 (DO-4).
1.4 Maximum ratings.
Types
VRWM
IO
IF
TJ and
IFSM at:
Barometric
Pressure
TC = +25°C TC = +150°C
TSTG
t = 1/120 s
(reduced)
TC = +150°C
(1)
°C
V (pk)
A dc
A dc
A dc
A
mm Hg
1N1614, R
200
10
5
15
-65 to +175
100
8
1N1615, R
400
10
5
15
-65 to +175
100
8
1N1616, R
600
10
5
15
-65 to +175
100
16
5
1N4458, R
800
10
15
-65 to +175
100
30
1N4459, R
1,000
10
5
15
-65 to +175
100
54
(1) Derate linearly at 66.67 mA dc/°C above TC = +25°C.
