MIL-PRF-19500-162 Semiconductor Devices, Diode, Silicon, Power Rectifier, Types 1N1614, 1N1615, 1N1616, 1N4458, 1N4459, 1N1614R, 1N1615R, 1N1616R, 1N4458R, 1N4459R, Jan And JantxThis specification covers the performance requirements for silicon, power rectifier diodes. Two levels of product assurance are provided for each device as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9


. . . . . .
MIL-PRF-19500/162E
TABLE I. Group A inspection.
1/
Inspection 1/
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 1
Visual and mechanical
2071
examination
Subgroup 2
IF = 15 A(pk), tP ≤ 8.3 ms,
Forward voltage
4011
VF
1.5
V (pk)
duty cycle ≤ 2 percent, pulsed
(see 4.5.1)
µA dc
Reverse current
4016
DC method; VR = rated V
IR1
50
leakage
RWM (see 1.4)
°C/W
ZθJX
Thermal impedance
3101
See 4.3.2
4.5
Subgroup 3
µA dc
Reverse current
4016
DC method; VR = rated V
IR2
500
leakage
RWM (see 1.4) TC = +150°C
Subgroups 4, 5, 6, and 7
Not applicable
1/ For sampling plan, see MIL-PRF-19500.
