MIL-PRF-19500-162 Semiconductor Devices, Diode, Silicon, Power Rectifier, Types 1N1614, 1N1615, 1N1616, 1N4458, 1N4459, 1N1614R, 1N1615R, 1N1616R, 1N4458R, 1N4459R, Jan And JantxThis specification covers the performance requirements for silicon, power rectifier diodes. Two levels of product assurance are provided for each device as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9

MIL-PRF-19500/162E

Symbol

Dimensions

Notes

Inches

Millimeters

Min

Max

Min

Max

.250

6.35

CD1

.424

10.77

.405

10.29

.060

1.52

.424

.437

10.77

11.10

.075

.175

1.91

4.45

OAH

.800

20.32

6,7,8

.422

.453

10.72

11.51

.060

1.52

NOTES:

1. Dimensions are in inches.

2. Millimeter equivalents are given for general information only.

3. Angular orientation of this terminal is undefined.

4. Diameter of unthreaded portion .189 inch (4.80 mm) maximum; .163 inch (4.14 mm) minimum.

5. The A.S.A. thread reference is 10-32UNF2A (unplated).

6. The maximum diameter of plated threads shall be basic pitch diameter .169 inch (4.29 mm).

7. Unit shall not be damaged by torque of 15 inch-pound applied to 10-32NF2B nut assembled on thread.

8. Complete threads shall extend to within 2.5 threads of the seating plane.

9. Terminal end shape is unrestricted.

10. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.

FIGURE 1. Physical dimensions.
