MIL-PRF-19500-225 Semiconductor Device, Transistor, Npn, Silicon, Types 2N1711, 2N1711S, 2N1890, And 2N1890S, Jan, Jantx, And JantxvThis specification covers the performance requirements for NPN, silicon, low-power transistors. Two levels of product assurance are provided for each device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16

MIL-PRF-19500/225K

* TABLE II. Group E inspection (all quality levels) - for qualification or re-qualification only.

MIL-STD-750

Qualification

Inspection

Method

Conditions

Subgroup 1

45 devices

c=0

1051

Test condition C, 500 cycles

Temperature cycling

(air to air)

1071

Hermetic seal

Fine leak

Gross leak

See table I, subgroup 2 herein.

Electrical measurements

Subgroup 2

45 devices

c=0

Intermittent life

1037

Intermittent operation life: VCB = 10 V dc, 6,000 cycles

Adjust device current, or power, to achieve a minimum

ĆTJ of +100�C.

Electrical measurements

See table I, subgroup 2 herein.

Subgroup 4

Thermal impedance curves

See table E-IX of MIL-PRF-19500, group E, subgroup 4.

Subgroup 5

Not applicable

Subgroup 6

3 devices

Electrostatic discharge

1020

(ESD)

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B.
