The documentation and process conversion
measures necessary to comply with this revision
INCH-POUND
shall be completed by 12 September 2011.
MIL-PRF-19500/290P
12 August 2011
SUPERSEDING
MIL-PRF-19500/290N
20 September 2010
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, SWITCHING, TYPES, 2N2904,
2N2904A, 2N2904AL, 2N2905, 2N2905A, AND 2N2905AL, JAN, JANTX, JANTXV, JANS,
JANTXVM, JANTXVD, JANTXVR, JANTXVH, JANSM, JANSD, JANSR, AND JANSH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, silicon, switching transistors. Four
levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Provision for radiation
hardness assurance (RHA) to four radiation test levels is provided for JANTXV and JANS product assurance levels for
type 2N2905A. RHA level designators "M", "D", "R", and "H" are appended to the device prefix to identify devices
which have passed RHA requirements.
1.2 Physical dimensions. See figure 1 herein (similar to TO-39).
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
PT = (1)
Types
PT = (2)
VCBO
TSTG and TJ
VCEO
VEBO
IC
RθJC
RθJA
TA =
TC =
+25°C
+25°C
(1) (2)
(1) (2)
°C
°C/W
°C/W
W
W
V dc
V dc
V dc
mA dc
2N2904 (1)
0.8
3.0
60
40
5
600
-65 to +200
195
50
2N2905 (1)
0.8
3.0
60
40
5
600
-65 to +200
195
50
2N2904A, (2)
0.8
3.0
60
60
5
600
-65 to +200
195
50
2N2905A, (2)
0.8
3.0
60
60
5
600
-65 to +200
195
50
2N2904AL, (2)
0.8
3.0
60
60
5
600
-65 to +200
195
50
2N2905AL (2)
0.8
3.0
60
60
5
600
-65 to +200
195
50
(1) For derating, see figures 2 and 3.
(2) For thermal impedance, see figures 4 and 5.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime, ATTN:
VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST Online
AMSC N/A
FSC 5961
