MIL-PRF-19500/315G
* TABLE I. Group A inspection - Continued.
MIL-STD-750
Symbol
Limits
Unit
Inspection 1/
Method
Conditions
Min
Max
Subgroup 5
TC = +100C; powers application
Safe operating area (dc)
3051
time = 10 s (see figure 8)
Test 1
VCE = 80 V dc , IC = 80 mA dc
Test 2
VCE = 20 V dc, IC = 1.5 A dc
Safe operating area
See figures 4 and 5 (clamped
(clamped switching)
inductive load) TA = +25C;
IB = 0.5 A dc; IC = 5 A dc;
VCC = 15 V dc
Endpoint electrical
See table I, subgroup 2 herein.
measurements
Subgroups 6 and 7
Not applicable
1/ For sampling plan, see MIL-PRF-19500.
2/ For JANS level, all devices required by the specified sampling plan shall be subjected to subgroups 2, 3, and 4
combined.
13
