MIL-PRF-19500/315G

* TABLE II. Group E inspection (all quality levels) - for qualification and re-qualification only.

Inspection

Sample plan

MIL-STD-750

Method

Conditions

Subgroup 1

45 devices

c=0

Temperature cycling

1051

500 cycles, condition D.

Hermetic seal

1071

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2 herein.

Subgroup 2

45 devices

c=0

1,000 hours minimum, TA = 150C, VCB = 80 percent of

Blocking life

1048

rated.

Electrical measurements

See table I, subgroup 2 herein.

Subgroup 4

Thermal impedance curves

See table E-IX of MIL-PRF-19500, group E, subgroup 4.

11 devices

Subgroup 6

1020

ESD

45 devices

Subgroup 8

c=0

Reverse stability

1033

Condition B.
