MIL-PRF-19500/317R
Maximum Thermal Impedance
20x20 Chip in U LCC6 Pkg, Heavy PCB, Tsp=25C, Θjsp=210C/W, Side 1 of 2
1000
100
10
0.000001
0.00001
0.0001
0.001
0.01
0.1
1
10
Time (s)
FIGURE 13. Thermal impedance graph (RθJSP) for 2N2369AU and 2N3227U.
29
