MIL-PRF-19500/337L
* TABLE I. Group A inspection.
MIL-STD-750
Limit
Inspection 1/ 2/ 3/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 1
Visual and mechanical
2071
examination
Subgroup 2
°C/W
ZθJX
Thermal impedance
3101
See 4.3.2
IF = 100 µA dc (pulsed, see 4.5.1)
VF1
Forward voltage
4011
0.49
0.55
V dc
IF = 250 µA dc (pulsed, see 4.5.1)
VF2
Forward voltage
4011
0.53
0.59
V dc
IF = 1 mA dc (pulsed, see 4.5.1)
VF3
Forward voltage
4011
0.59
0.67
V dc
IF = 2 mA dc (pulsed, see 4.5.1)
VF4
Forward voltage
4011
0.62
0.70
V dc
IF = 10 mA dc (pulsed, see 4.5.1)
VF5
Forward voltage
4011
0.70
0.81
V dc
DC method; VR = 50 V dc
IR1
Reverse current
4016
50
nA dc
IR = 5 µA dc
VBR1
Breakdown voltage
4021
100
V dc
Subgroup 3
TA = +150°C
High temperature operation:
µA dc
DC method, VR = 50 V dc
IR2
Reverse current
4016
50
TA = -55°C
Low temperature operation:
IR = 5 µA dc
V(BR)2
Breakdown voltage
4021
75
V dc
Subgroup 4
VR = 0 V dc, f = 1 MHz,
Junction capacitance
4001
C
2.0
pF
Vsig = 50 mV (pk to pk), max
Condition A, IF = IRM = 10 mA dc
trr
Reverse recovery time
4031
4
ns
See method 4023 of MIL-STD-750,
Scope display evaluation
4023
figures 4023-3, 4023-7,4023 -9, 4023-10
only
Subgroup 5
