MIL-PRF-19500-337 Semiconductor Device, Silicon, Switching, Types 1N4153-1, 1N4153Ur-1, 1N4153Ub, 1N4153Ubca, 1N4153Ubcc, 1N4153Ubd, 1N4153Ubn, 1N4153Ubnd, 1N4534, And 1N4534Ub, Jan, Jantx, Jantxv, Janhc, And JankcThis specification covers the performance requirements for controlled forward voltage switching diodes. Three levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/337L
1N4153UB
1N4153UBCA
1N4153UBCC
1N4153UBD
Dimensions
Symbol
Inches
Millimeters
Note
Min
Max
Min
Max
BL
.115
.128
2.92
3.25
BW
.095
.108
2.41
2.74
BH
.046
.056
1.17
1.42
UB and UBN only, 4
CL
.128
3.25
CW
.108
2.74
LL1
.022
.038
0.56
0.97
3 places
LL2
.014
0.356
3 places
.035
.039
0.89
0.99
LS1
.071
.079
1.80
2.01
LS2
LW
.016
.024
0.41
0.61
r1
.012
0.30
5
r2
.022
0.56
UB and UBC only, 5
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Hatched areas on package denote metallized areas.
4. Pad 1 = Base, Pad 2 = Emitter, Pad 3 = Collector, Pad 4 = Shielding connected to the lid.
5. For design reference only.
6. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.
6
