MIL-PRF-19500/366P
1
Symbol
Dimensions
Inches
Millimeters
Min
Max
Min
Max
BL
.215
.225
5.46
5.72
BW
.145
.155
3.68
3.94
CH
.049
.075
1.24
1.91
LH
.020
0.51
LW1
.135
.145
3.43
3.68
LW2
.047
.057
1.19
1.45
LL1
.085
.125
2.16
3.18
LL2
.045
.075
1.14
1.91
LS1
.070
.095
1.78
2.41
LS2
.035
.048
0.89
1.22
Q1
.030
.070
0.76
1.78
Q2
.020
.035
0.51
0.89
1
Collector
2
Base
3
Emitter
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Terminal 1 is collector.
4. Terminal 2 is base.
5. Terminal 3 is emitter.
6. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.
FIGURE 3. Physical dimensions and configuration U4.
5
