INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/369H
shall be completed by 15 October 2010.
15 July 2010
SUPERSEDING
MIL-PRF-19500/369G
10 August 2009
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER,
TYPE 2N3441, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, power transistor. Three
levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (similar to TO-66).
1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
PT
VCBO
VCEO
VEBO
VCER
IB
TSTG and
RθJA
RθJC
IC
TA = +25°C
TC = +25°C
TJ
(2)
(1)
(1)
°C/W
°C/W
°C
W
W
V dc
V dc
V dc
V dc
A dc
A dc
3.0
25
160
140
7.0
150
2.0
3.0
58.5
3
-65 to +200
(1) For derating see figures 2 and 3.
(2) For thermal impedance see figure 4.
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
