MIL-PRF-19500/369H
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 5
TC = +25°C, t = 1 s, 1 cycle,
Safe operating area
3051
(dc operation)
see figure 6 and 7.
Test 1
IC = 3 A dc, VCE = 8.33 V dc
Test 2
IC = 833 mA dc, VCE = 30 V dc
Test 3
IC = 178.5 mA dc,
VCE = 140 V dc
Electrical measurements
See table I, subgroup 2 herein.
Subgroups 6 and 7
Not applicable
1/
For sampling plan see MIL-PRF-19500.
2/
This test required for the following end-point measurements only:
Group B, subgroups 2 and 3 (JAN, JANTX and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
